interior loft

[salvatore]

Some shaders are not working and I used LW9.3 these settagi:
150% light Sunspot inverse distance 1 km, 2 cone and soft edge .55.
Kray: range 1.7 exposure 1.7. Photon power 1.1 render preset High.
correct? need more light? how can I not create too lit areas if the increased power of the sun?
Thanks for your important recommendations

[Janusz Biela]

Some shaders are not working and I used LW9.3 these settagi:
150% light Sunspot inverse distance 1 km, 2 cone and soft edge .55.
Kray: range 1.7 exposure 1.7. Photon power 1.1 render preset High.
correct? need more light? how can I not create too lit areas if the increased power of the sun?
Thanks for your important recommendations

Washing renders...looks raytracing

Power in Kray You have totaly big... I thing good idea is make this parametr maximum 0.2-0.3, and recurse 20;
Forget lights from outside (use only blue background for reflection) rest light from Area light outside room (around 1-2 m behinde windows , 30 % smaller then windows , inverse dist 2 , colour blue + Shader Power around 20-50)
Of coarse this will make dark render ...but next You must put on ceiling around 4 small area light per room (orange or beige colour) with big Power Shader around 100-150.
Exponential 2.0. .. this is my sugestions.
btw : if You use sun Turn On Power shader for this (colour beige) around 6-10.
Background view must have Raytracing Shader and "Unseen by radiosity"

[jure]

Some shaders are not working and I used LW9.3 these settagi:
150% light Sunspot inverse distance 1 km, 2 cone and soft edge .55.
Kray: range 1.7 exposure 1.7. Photon power 1.1 render preset High.
correct? need more light? how can I not create too lit areas if the increased power of the sun?
Thanks for your important recommendations

I guess you are using Lightmap. My suggestion is similar to johny's. Try quick LWF plugin - gamma 2.2 and gamma 2.2 in Kray GUI. Photon power in Kray GUI 0.1-0.2 (to make darker shadows), add power multiplier to Sun (20-30) (to get more light for sun). Next you can use area lights like johny said or use luminous skydome with power.
Light must bounce, warm color from sun, blue from sky....

[nico]

Some shaders are not working and I used LW9.3 these settagi:
150% light Sunspot inverse distance 1 km, 2 cone and soft edge .55.
Kray: range 1.7 exposure 1.7. Photon power 1.1 render preset High.
correct? need more light? how can I not create too lit areas if the increased power of the sun?
Thanks for your important recommendations

Washing renders...looks raytracing

Power in Kray You have totaly big... I thing good idea is make this parametr maximum 0.2-0.3, and recurse 20;
Forget lights from outside (use only blue background for reflection) rest light from Area light outside room (around 1-2 m behinde windows , 30 % smaller then windows , inverse dist 2 , colour blue + Shader Power around 20-50)
Of coarse this will make dark render ...but next You must put on ceiling around 4 small area light per room (orange or beige colour) with big Power Shader around 100-150.
Exponential 2.0. .. this is my sugestions.
btw : if You use sun Turn On Power shader for this (colour beige) around 6-10.
Background view must have Raytracing Shader and "Unseen by radiosity"

but this setup iss for kray rc2?
why color blue?

[salvatore]

this setup is with LW 9.3 and Kray 2 RC1.4.
Many tools do not work.
Today I downloaded the new release of Kray.
I expect better performance

[erwin zwart]

this setup is with LW 9.3 and Kray 2 RC1.4.
Many tools do not work.
Today I downloaded the new release of Kray.
I expect better performance

which tools do not work? Why are you using LW 9.3 btw? You miss out on some kray goodies in 9.6 this way.

[salvatore]

thanks for the advice.
From today I have LW 9.6 and Kray 2
Soon you submit to you more images.
Today I did a test and finally all the instruments work very well

For previous images I had to use the trick ..
thanks
